Chapter-9
Appendix
L-46X User's Manual
113
1st
Item
Specification
Note
GS1/Composite
Symbologies
GS1 DataBar , GS1 DataBar Limited ,
GS1 DataBar Expanded
Composite GS1 DataBar ,
Composite GS1-128 ,
Composite EAN , Composite UPC
GS1 DataBar:
formerly called “RSS”
Minimum resolution
GS1 DataBar
Composite Code
: 0.169 mm
: 0.169 mm
PCS 0.9
Supported 2D Symbologies
Symbologies
PDF417, MicroPDF417, Codablock F, QR
Code , Micro QR Code, DataMatrix (ECC 200),
MaxiCode, Aztec Code, Chinese Sensible
Code
Disable Code 128
when Codablock F is
enabled.
Minimum resolution (mm)
PDF417
QR Code
Data Matrix
: 0.169 mm
: 0.169 mm
: 0.169 mm
PCS 0.9
Depth of
field
(Typ)
PDF417
Resolution (0.169)
8 105 mm
Resolution (0.254)
1 170 mm
QR Code
Resolution (0.169)
19 70 mm
Resolution (0.381)
0 209 mm
Data Matrix
Resolution (0.169)
21 75 mm
Resolution (0.254)
2 132 mm
Common
Scan angle
Pitch ±65°
Skew ±65°
Tilt 360°
Minimum PCS
0.2 or more
MRD: 13% or more
OCR
OCR font
Machine Readable Travel Documents,
OCR-A/B
Imager
Image data format
Windows Bitmap, JPEG
Shades of gray
1024, 256, 16, 2
Range of output image
Select top/bottom (column) and left/right (row)
Resolution of output image
Full,1/2, 1/4
Interface of output image
RS-232C, USB-COM
Baud rate
USB-COM (full speed)
About 3 sec
Resolution: Full
RS-232C
(baud rate: 115.2 kbps)
About 40 sec
