Chapter-9
Appendix
L-46X User's Manual
111
1st
Code option
]AIM-ID
Code option
]AIM-ID
DataMatrix options AIM/ISO15424 Code ID: d*
ECC200
]d1
ECC200, supporting ECI protocol
]d4
ECC200, FNC1 IN 1st or 5th position
]d2
ECC200,FNC1 in 1st or 5th position
and supporting ECI protocol
]d5
ECC200, FNC1 IN 2nd or 6th position
]d3
ECC200,FNC1 in 2nd or 6th position
and supporting ECI protocol
]d6
Aztec options AIM/ISO15424 Code ID: z*
No structure/other
]z0
Structured append header included,
FNC1 following an initial letter
or pair of digits
]z8
FNC1 preceding 1st message character
]z1
FNC1 following an initial letter
or pair of digits
]z2
Structured append header included
and
ECI protocol implemented
]z9
ECI protocol implemented
]z3
FNC1 preceding 1st message character
and ECI protocol implemented
]z4
Structured append header included,
FNC1 preceding 1st message
character,
ECI protocol implemented
]zA
FNC1 following an initial letter or pair of
digits, ECI protocol implemented
]z5
Structured append header included,
FNC1 following an initial letter or pair
of digits, ECI protocol implemented
]zB
Structured append header included
]z6
Structured append header included and
FNC1 preceding 1st message character
]z7
Aztec runes
]zC
QR Code option AIM/ISO15424 Code ID: Q*
Model 1
]Q0
Model 2, ECI protocol implemented
]Q4
Model 2, ECI protocol not implemented
]Q1
FNC1 in first position
Model 2, ECI protocol implemented
]Q2
Model 2, ECI protocol not
implemented
]Q5
Model 2, ECI protocol not implemented
FNC1 in first position
]Q3
FNC1 in second position
Model 2, ECI protocol implemented
]Q6
FNC1 in second position
Maxi Code option AIM/ISO15424 Code ID: U*
Symbol in mode 4 of 5
]U0
Symbol in mode 4 of 5,
ECI protocol implemented
]U2
Symbol in mode 2 of 3
]U1
Symbol in mode 2 of 3,
ECI protocol implemented
]U3
