Chapter-9
Appendix
L-46X User's Manual
109
1st
Code option
]AIM-ID
Code option
]AIM-ID
Code 39 option AIM/ISO15424 Code ID : A*
Normal Code 39 (D5)
Not check CD (C1)
Transmit CD (D9)
]A0
Full ASCII Code 39 (D4) or
Full ASCII Code 39 if pos. (+K)
Not check CD (C1)
Transmit CD (D9)
]A4
Normal Code 39 (D5)
Check CD (C0)
Transmit CD (D9)
]A1
Full ASCII Code 39(D4) or
Full ASCII Code 39 if pos. (+K)
Check CD (C0)
Transmit CD (D9)
]A5
Normal Code 39 (D5)
Not check CD (C1)
Not transmit CD (D8)
]A2
Full ASCII Code 39(D4) or
Full ASCII Code 39 if pos. (+K)
Not check CD (C1)
Not transmit CD (D8)
]A6
Normal Code 39 (D5)
Check CD (C0)
Not transmit CD (D8)
]A3
Full ASCII Code 39(D4) or
Full ASCII Code 39 if pos. (+K)
Check CD (C0)
Not transmit CD (D8)
]A7
Codabar option AIM/ISO15424 Code ID : F*
Codabar normal mode (HA)
Not check CD (H7)
Transmit CD (H8)
]F0
Codabar normal mode(HA)
Not check CD (H7)
Not transmit CD (H9)
]F4
Codabar ABC (H4) or (H3)
Not check CD (H7)
Transmit CD (H8)
]F1
Codabar ABC (H4) or (H3)
Not check CD (H7)
Not transmit CD (H9)
]F5
Codabar normal mode (HA)
Check CD (H6)
Transmit CD (H8)
]F2
Codabar normal mode (HA)
Check CD (H6)
Not transmit CD (H9)
]F6
Codabar ABC (H4) or (H3)
Check CD (H6)
Transmit CD (H8)
]F3
Codabar ABC (H4) or (H3)
Check CD (H6)
Not transmit CD (H9)
]F7
Interleaved 2 of 5 option AIM/ISO15424 Code ID : I*
Not check CD (G0)
Transmit CD (E0)
]I0
Not check CD (G0)
Not Transmit CD (E1)
]I2
Check CD (G1)
Transmit CD (E0)
]I1
Check CD (G1)
Not Transmit CD (E1)
]I3
