Page #10 background image
range Pi User Manual Copyright reserved by Shenzhen Xunlong Software Co., Ltd
2
1.3.
Hardware Features of Orange Pi 3B
Introduction to hardware features
Master chip
Rockchip RK3566
CPU
Quad-core 64-bit Cortex-A55 processor, 22nm advanced
technology, main frequency up to 1.8GHz
GPU
·ARM Mali G52 2EE graphics processor
·Support OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1
·Embedded high-performance 2D acceleration hardware
NPU
· Integrated RKNN NPU AI accelerator, 0.8Tops@INT8
performance
· Supports one-click conversion of
Caffe/TensorFlow/TFLite/ONNX/PyTorch/Keras/Darknet
architecture models
VPU
·
4K@60fps H.265/H.264/VP9 video decoding
·
1080P@100fps H.265 video encoding
·
1080P@60fpsH.264 video encoding
PMU
Rockchip RK809-5
Memory
2GB/4GB/8GB
LPDDR4/4x
storage
·
Support eMMC module: 16GB/32GB/64GB/128GB/256GB
·
SPI Flash: 16MB/32MB
·
M.2 M-KEY slot: SATA3 or PCIe2.0 NVME SSD
·
TF card slot
Wi-Fi+Bluetooth
Wi-Fi 5+BT 5.0BLE20U5622
ethernet
transceiver
10/100/1000Mbps Ethernet (onboard PHY chip: YT8531C)
show
·1x HDMI TX 2.0, maximum support 4K@60FPS
·1xMIPI DSI 2 Lane
·eDP1.3
