range Pi User Manual Copyright reserved by Shenzhen Xunlong Software Co., Ltd
10
9) 5V cooling fan. As shown in the figure below, the development board has an interface
for connecting the cooling fan, and the interface specification is 2pin 1.25mm pitch
The fan on the development board can adjust the speed and switch through
PWM.
10) 100M or 1000M network cable, used to connect the development board to the
Internet
11) USB2.0 male-to-male data cable, used to burn images to eMMC, NVMe SSD and
other functions
