range Pi User Manual Copyright reserved by Shenzhen Xunlong Software Co., Ltd

255

c. Restart QT Creator after the Settings are complete

d. Then make sure that QT Creator uses the GCC compiler, if the default is Clang,

change it to GCC

Debian12 Please skip this step.
