C When the misfeed indicators light at A, C and D, remove misfed paper from A
and C first then remove it in the ADU (D).
C Make sure that the misfeed indicator goes off after removing all misfed paper.
C Open Paper Guide Plate a completely or fingers might be wedged.
ATTENTION
3
Push back automatic duplex unit.
I
F
1
Pull out automatic duplex unit.
2
■■
■■
■ Automatic Duplex Unit (ADU)
Handling
Paper Guide Plate
aa
aa
a.
Paper Guide Plate
bb
bb
b.
# Open paper guide plate a.
$ Open paper guide plate b.
% Remove misfed paper.
& Close paper guide plate b.
( Close paper guide plate a.
