4.10 Resource Programming
EIA (RS-232C) Parameters — Port 1 / Port 2 (contd.)
806-807
System Programming 4-133
7. Press STORE.
8. Press NEXT to program word length.
Display example: Word Lengt:8bits
9. Keep pressing SELECT until the desired selection is
displayed.
10. Press STORE.
11. Press NEXT to program parity bit.
Display example: Parity:Mark
12. Keep pressing SELECT until the desired selection is
displayed.
13. Press STORE.
14. Press NEXT to program stop bit.
Display example: Stop Bit:1bit
15. Keep pressing SELECT until the desired selection is
displayed.
16. Press STORE.
17. Press END.
Conditions • The following combinations are invalid.
• The program address of the out-of-service system port is unacceptable.
Feature References Section 3, Features,
Station Message Detail Recording (SMDR)
Parity
Mark
Space
Space
Word Length
8
8
8
Stop Bit
2
1
2
