Control with Communication Port
Reading Setting Data
Reading from the Storage Space in PV500
?? = 00 - 99 (No. of storage area saving the data to read)
Receive
Error (ERROR 1 signal = ON)
Error code
When waiting for Individual Trigger input*, image capturing of the rest of the
cameras or Abort Inspection/Process is not executed in 10 seconds after
sending the command to execute Type Switch. (This condition does not apply
when Individual Trigger Timeout is set to "Yes")
* The status where the device is waiting for the rest of camera triggers after
receiving some of the camera triggers.
Other number than 00-99 was specified for a saving area number.
• The data file is incompatible. (Data of the later version, etc.)
• The number and types of cameras connected to PV500 is different
from the Camera setting of the data file.
(including the case that the camera is unconnected because the camera
cable came off unexpectedly.)
Reading from a SD memory card
Send
?? = 00 - 99 (No. of storage area of SD memory card saving
Receive
Error (ERROR 1 signal = ON)
Error code
When waiting for Individual Trigger input*, image capturing of the rest of the
cameras or Abort Inspection/Process is not executed in 10 seconds after
sending the command to execute Type Switch. (This condition does not apply
when Individual Trigger Timeout is set to "Yes")
* The status where the device is waiting for the rest of camera triggers after
receiving some of the camera triggers.
Other number than 00-99 was specified for a saving area number.
• No SD memory card is attached or cannot be accessed.
• No data file in the designated area of a SD memory card..
• The data file is not data of PV500.
• The Data file is incompatible. (Data of the later version, etc.)
• The number and types of cameras connected to PV500 is different from
the Camera setting of the data file. (including the case that the camera is
unconnected because the camera cable came off unexpectedly.)
