483
INDEX
Appendix
Command Meaning Send Receive
Refer
to
%PWP$FECnnn:LPAIR(BCC)
Write / Checker / Feature Extraction / OK
Judge. Max. and Min.
Yes
411
413
%PWP$FWCnnn:LPAIR(BCC)
Write / Checker / Flaw Detection / OK
Judge. Max. and Min.
Yes
411
413
%PWP$GECnnn:LPAIR(BCC)
Write / Checker / Gray Edge / OK Judge.
Max. and Min.
Yes
411
413
%PWP$GGCnnn:APAIR(BCC)
Write / Geometry Calculation / Geometry
Calculation / Max. and Min. Angle
Yes
411
415
%PWP$GGCnnn:CAPAIR(BC
C)
Write / Geometry Calculation / Geometry
Calculation / Max. and Min. Intersect. Angle
Yes
411
415
%PWP$GGCnnn:DPAIR(BCC)
Write / Geometry Calculation / Geometry
Calculation / Max. and Min. Distance
Yes
411
415
%PWP$GGCnnn:LAPAIR(BC
C)
Write / Geometry Calculation / Geometry
Calculation / Max. and Min. Major Axis
Yes
411
415
%PWP$GGCnnn:RPAIR(BCC)
Write / Geometry Calculation / Geometry
Calculation / Max. and Min.Radius
Yes
411
415
%PWP$GGCnnn:SAPAIR(BC
C)
Write / Geometry Calculation / Geometry
Calculation / Max. and Min. Minor Axis
Yes
411
415
%PWP$GGCnnn:SPAIR(BCC)
Write / Geometry Calculation / Geometry
Calculation / Max. and Min. Standard
Deviation
Yes
411
415
%PWP$GGCnnn:XPAIR(BCC)
Write / Geometry Calculation / Geometry
Calculation / Max. and Min. X
Yes
411
415
%PWP$GGCnnn:YPAIR(BCC)
Write / Geometry Calculation / Geometry
Calculation / Max. and Min. Y
Yes
411
415
%PWP$GWCnnn:LPAIR(BCC)
Write / Checker / Gray Window / OK Judge.
Max. and Min.
Yes
411
413
%PWP$LICnnn:DPAIR(BCC)
Write / Checker / Line / Max. and Min. No. of
Pixels
Yes
411
412
%PWP$LICnnn:LPAIR(BCC)
Write / Checker / Line / Max. and Min. No. of
Objects
Yes
411
412
%PWP$MRKcg_MOVE(BCC)
c: Camera No.(0-3)
g: Marker No.(0-7)
Write / Marker / Central Coordinate Moving
Distance Set
Yes
411
416
%PWP$SECnnn:CPAIR(BCC)
Write / Checker / Smart Edge(Circle) / Max.
and Min. Circularity
Yes
411
414
%PWP$SECnnn:LPAIR(BCC)
Write / Checker / Smart Edge(Circle) / Max.
and Min. Measurement
Yes
411
414
%PWP$SECnnn:SPAIR(BCC)
Write / Checker / Smart Edge(Circle) / Max.
and Min. Standard Deviation
Yes
411
414
%PWP$SELnnn:LIPAIR(BCC)
Write / Checker / Smart Edge(Line) / Max.
and Min. Linearity
Yes
411
415
