5.1.1. Menu Settings -System Setup - Port Setup - continue-
1020 Indicator
Select a parity for the protocol. Choose between None, Odd, Even, Mark and
Space.
Select a speed for the protocol. Choose between 1200, 2400, 4800, 9600, 19200,
38400, 57600 and 115200 pbs.
Only active when protocol ASCII is chosen. Selected indicator will be sent out
over the communication port. Choose a number between 0 and 100.
For explanation of the options, see appendix I.
RS422 Port
In this menu, all settings for the RS422 comport can be set.
Scroll through the RS422 Port menu using the UP or DOWN key. Press Enter for
editing the setting.
27
