13 - 40
Adjustment
13.06.03 Knife height
Requirement
When the edge trimmer is engaged, the centre of the angular knife opening must be at the
same height as the upper edge of the needle plate.
1
Fig. 13 - 36
● Switch off the machine and engage the edge trimmer.
● Adjust milled screw 1 according to the requirement.
The basic setting may be changed depending on the material thickness.
61-056
