Pfaff 1571 - Seam Programming Examples

Input
11 - 9
11.05 Seam programming examples
The procedure for creating seam programs using the seam program input function and the
Teach In function is described below with the help of examples.
The display settings shown in the examples only appear like this if no seam pro-
gram has been entered under the selected program number.
11.05.01 An example for seam program input
The seam to be programmed should
- have 5 seam sections
- be stored under program number 7.
● Switch on the machine
P
7
7
PM
2.5 2.5
● Select input mode by pressing TE/Speed key twice.
2x
No VAL
101 II
TE
● Press PM to select the seam program input function.
● Enter the code number, see Chapter 9.10 Entering/changing the code number.
● Select the program number "7" with the corresponding +/- key.
● Confirm the selection made with the corresponding +/- key.
● The display changes for the input of the first seam section.
