13 - 52
Adjustment
1 101 Start backtack, pedal-controlled I -II I I
(I = OFF, II = ON)
102 Reversing I -II I I
(I = OFF, II = ON)
103 Stitch placement I - II I I
(I = OFF, II = ON)
104 Bobbin thread monitoring
(0 = OFF, I = reverse counter,
2 = thread monitor) 0 - 2 0 0
105 Bobbin thread reverse counter 0 - 99999 12000 12000
106 Remaining bobbin thread counter 0 - 999 100 100
108 Display software version of main processor 0329/…
109 Display software version of
stepping motor processor 0305/....
110 Display software version of the control panel V004H202
111 Display software version of the sewing drive V35
112 Key tone of the control panel
I = off, II = on I - II II II
113 Beep tone for section change
I = off, II = on I - II I I
2 201 Machine configuration
1 = 1571 + 1591, 2 = 1571 + 1591 with sensor
6 = 1574, 7 = 1574 with sensor 1 - 7 1 1
202 Lowering speed roller presser
I = slow, II = quick I - II I I
203 Allocation single stitch key
I = single stitch, II = needle raised I - II I I
204 Allocation semi-stitch key
I = semi-stitch, II = needle raised I - II I I
3 301 Position take-up lever t.d.c. 0 - 191 3 -
0 - 127 - 125
13.08.02 List of parameters
The operator has free access to the "100" parameters. Parameters
"200" - "800" can only be changed after entering a code number and
many only be changed by authorised personnel.
Parameter
Setting
range
Set value
1574
Description
Set value
1571/1591
Group
