13 - 53
Adjustment
3 302 Position needle lowered 0 - 127 35 17
303 Position cutting solenoid "on" 0 - 127 35 17
304 Position cutting solenoid "tacting" 0 - 127 155 100
305 Position cutting solenoid "off" 0 - 127 185 120
306 Reverse position 0 - 127 155 100
307 Placement stitch position 0 - 127 7 7
308 Position thread tension release 0 - 127 170 98
4 401 Delay time lifting roller presser (s) 0.01 - 1.50 0.02 0.02
402 Start delay after lowering roller presser (s) 0.01 - 1.50 0.15 0.15
403 Set lift roller presser (s) 0.01 - 0.20 0.03 0.03
404 Tact thread cutting solenoid (%) 10 - 50 35 35
405 Time for cleaning thread monitor (s) 0.01 - 1.50 0.25 0.25
5 501 Maximum speed 100 - 3500 2600 3500
502 Speed start backtack 100 - 1500 700 700
503 Speed end backtack 100 - 1500 700 700
504 Speed soft start 100 - 3500 1500 700
505 Soft start stitches 0 - 15 0 0
6 601 Move stepping motor roller presser and
feed wheel
602 Display inputs
0123456789ABCDEF
0: Centre position needle(1571, 1591) E16
1: End position needle(1571, 1591) E15)
2: Coding intermittent (E14)
3: not assigned (E13)
4: not assigned (E12)
5: not assigned (E11)
6: not assigned (E10)
7: not assigned (E9)
8: not assigned (E8)
9: Bobbin thread error (E7)
A:Knee switch (E6)
B:Sensor (E5)
C:Start inhibitor (E4)
D:Single stitch key on machine head (E3)
E:Semi-stitch key on machine head (E2)
F:Reverse stitch key on machine head (E1)
Parameter
Setting
range
Set value
1574
Description
Set value
1571/1591
Group
