13 - 54
Adjustment
603 Basic position of the machine drive unit
(see Chap. 8.02.04 and 8.02.05 ) - (8±3)
604 Carry out cold start (see Chap. 13.11)
605 Stitch formation check by turning the balance wheel
7 701 P-quota speed controller 1 - 50 20 30
702 I-quota speed controller 0 - 100 50 50
703 P-quota position controller 1 - 50 20 20
704 D-quota position controller 1 - 100 30 30
705 Time for position controller 0 - 100 25 25
706 P-quota position controller for rest brake 1 - 50 25 25
707 D-quota position controller for rest brake 1 - 50 15 15
708 Maximum moment for rest brake 0 - 100 0 0
709 Minimum machine speed 3 - 64 6 6
710 Maximum machine speed 1 - 35 26 35
711 Maximum motor speed 1 - 35 40 35
712 Positioning speed 3 - 25 18 18
713 Acceleration ramp 1 - 50 35 35
714 Brake ramp 1 - 50 30 30
715 Reference position 0 - 127 35 17
716 Time-out 0 - 255 40 40
717 Starting current motor 3 - 10 8 8
718 Anti-vibration filter 1 - 10 6 6
719 Rotation direction allocation 0 - 1 0 0
720 Reference position correction 1 - 127 64 64
8 801 Right of access function group 100 0 - 1 0 0
802 Right of access function group 200 0 - 1 1 1
803 Right of access function group 300 0 - 1 1 1
804 Right of access function group 400 0 - 1 1 1
Parameter
Setting
range
Set value
1574
Description
Set value
1571/1591
Group
