Pfaff 1571 - Basic Machine Adjustment: Needle Position (1574)

13 - 3
Adjustment
13.04.02 Positioning the needle in the direction of sewing PFAFF 1574
Requirement
The needle must penetrate the middle of the needle hole as viewed in the direction of
sewing.
3
3
Fig. 13 - 02
● Move the needle bar frame 1 ( screws 2 and 4 and nut 3 ) in accordance with the
requirement.
Screws 4 are accessible through the holes on the back of the housing.
2
4
1
