Pfaff 1571 - Teach-In Method Seam Input Example

Input
11 - 16
● Select input mode by pressing TE/Speed key twice.
2x
No VAL
101 II
TE
● Press PM to select the seam program input function.
● Enter the code number, see Chapter 9.10 Entering/changing the code number.
● By pressing the Scroll key, select the input variant "Seam input with Teach In", see
Chapter 11.02 Seam program input variants.
● Select the program number "8" with the corresponding +/- key.
● Confirm the selection made with the corresponding +/- key.
The display changes for the input of the first seam section.
T
8
PM
11.05.02 Seam input example using the Teach In method
The seam to be programmed should
- have 3 seam sections
- and be stored under program number 8.
● Switch on the machine
2.5 2.5
