Pfaff 1571 - Needle;Hook Adjustment (PFAFF 1574)

13 - 8
Adjustment
61
-
024
7
7
8
8
0,8 - 1 mm
61-025
5
2
12
11
13
14
3
4
6
1
Fig. 13 - 06
16
17
13
.04.06 Needle rise, hook clearance, needle height and needle guard on the PFAFF 1574
Requirement
With the needle bar positioned 2,0 mm after BDC on both hooks
1. the hook point must be at needle centre with a hook-to-needle clearance of
0.05 to 0.1 mm;
2. the top of the needle eye must be 0.8 to 1.0 mm below the hook points;
3. the needle guard 9 must touch the needle lightly.
86-008
10
15
86-009
10
9
