13 - 1
Adjustment
13 Adjustment
Unless stated otherwise, during all adjustment work the machine must be
disconnected from the electric and pneumatic power supply!
Danger of injury if the machine is started accidentally!
13.01 Notes on adjustment
All following adjustments are based on a fully assembled machine and may only be carried
out by expert staff trained for this purpose.
Machine covers, which have to be removed and replaced to carry out checks and
adjustments, are not mentioned in the text.
The order of the following chapters corresponds to the most logical work sequence for
machines which have to be completely adjusted. If only specific individual work steps are
carried out, both the preceding and following chapters must be observed.
Screws, nuts indicated in brackets ( ) are fastenings for machine parts, which must be
loosened before adjustment and tightened again afterwards.
13.02 Tools, gauges and other accessories
1 set of screwdrivers with blade widths from 2 to 10 mm
1 set of wrenches with jaw widths from 7 to 13 mm
1 set of Allan keys from 1.5 to 6 mm
1 metal ruler (Part no. 08-880 218-00)
1 adjustment pin (needle position in direction of sewing Part no. 61-111 641-46)
1 adjustment gauge (Part No. 08-880 136-01)
1 adjustment gauge (Part No. 61-111 643-33)
1 locking pin for needle bar rise (Part No. 61-111 641-39)
13.03 Abbreviations
t.d.c. = top dead centre
b.d.c. = bottom dead centre
