Pfaff 1571 - Lever for Raising the Roller Presser; Swing out Roller Presser

7 - 4
Controls
7.07 Lever for raising the roller presser
● The roller presser is raised by turning
lever 1.
Fig. 7-07 shows the 1574.
7.08 Swing out roller presser
● When roller presser 1 is raised, it is
possible to disengage it by pulling it
down slightly.
63-023
Fig. 7 - 07
1
Fig. 7 - 08
1
