12 - 3
Care and maintenance
61-019
12.04 Filling the oil reservoir of the thread lubrication unit
Control the oil level before each
use.
There must always be oil in the
reservoir 1.
● If necessary, fill oil up to mark through
hole.
We recommend
PFAFF thread lubricating oil,
Order No. 280-1-120 217.
Fig. 12 - 04
1
12
.05 Oiling the edge trimmer -726/05
● All moving parts and bearings marked
with arrows in Fig. 12-05 are to be
supplied with oil twice a week.
Use only oil with a mean
viscosity of 22.0 mm
2
/s at 40°C
and a density of 0.865 g/cm
3
at
15°C.
We recommend
PFAFF sewing machine oil
Best.-Nr. 280-1-120 144.
Fig. 12 - 05
