LIFEPAK 500 automated external defibrillator Parts Lists and Assembly Diagrams
12-28
Parts Lists
Case Replacement Kit, for Biphasic Unit with Readiness Display, PN 3010399-025
Item Quantity Part Number Part Description
3 1 3007973-001 LCD Shield
4 1 3005342-003 Upper Enclosure
7 4 802885-01 Mounting Foot
8 1 3011362-002 Lower Enclosure
9 12 202253-570 #6-32 × .375L PH Screw
14 1 3005346-000 Lower Case Corner
15 1 3005358-000 Patient Connector Door
17 2 3007670-000 Speaker Felt
19 1 3005356-003 Battery Plate Cavity
20 1 804234-02 Perimeter Seal
21 7 200536-008 Self-Locking Nylon Cable Tie Retainer, .10W × 5.50L
22 2 200536-011 Self-Locking Nylon Cable Tie Retainer, .35W × 21.0L
