LIFEPAK 500 automated external defibrillator Troubleshooting
8-12
Fault Code Table Page9of20
Code Fault Description
Corrective
Action
Code
5714 control_setup_third_shock_low_energy 6
5715 control_setup_third_shock_unknown_energy 6
5716 control_setup_invalid_cpr_time_interval 6
5717 control_setup_second_shock_invalid_energy 6
5718 control_setup_invalid_cpr_interval_selection 6
5719 control_service_wait_for_charge_timer_expired 8, 6, 4, 2
571a control_service_unknown_energy 6, 2
571b control_start_service_prompt_display_timer_failed 10
571c control_series_shock_counter_default_installed 6, 2
571d control_episode_shock_counter_default_installed 6, 2
571e control_selected_shock_energy_default_installed 6, 2
571f control_mode_default_installed 9, 6, 2
5720 control_state_default_installed 9, 6, 2
5721 control_tx_rx_shorted 7, 2
5722 control_user_test_charge_timer_expired 8, 6, 4, 2
5723 control_user_test_refuse_to_charge 8, 6, 4, 2
5724 control_normal_mode_charge_timer_expired 8, 6, 4, 2
5725 control_normal_mode_refuse_to_charge 6, 2
Corrective Action Code Key
Code Description
1 Try to reload the software
2 Replace the Main PCB
3 Replace the Connector
4 Replace the Energy Storage Capacitor
5 Replace the Inductor
6 Recalibrate/Restore Setup, Complete PIP,
Return to service if fault codes do not recur
7 Check the Wires
8 Check the Battery
9 Replace the Time-of-Day Clock Battery
10 Clear Faults, Complete PIP, Return to service
if fault codes do not recur
11 Replace the Biphasic PCB
