LIFEPAK 500 automated external defibrillator Troubleshooting
8-13
Fault Code Table Page 10 of 20
Code Fault Description
Corrective
Action
Code
5726 control_service_refuse_to_charge 6, 2
5727 control_setup_invalid_speaker_option 6
5800 defib_fault_minor 10
5801 shock_not_confirmed_by_dsp 2
5802 sensed_fet_xfer1_inactive_before_shock 2
5803 defib_voltage_over_target 2
5804 charging_overcurrent 2
5805 defib_charge_rate_too_low 8, 7, 4, 2
5806 defib_illegal_state_for_charging 10
5807 defib_illegal_state_for_shock 10
5808 defib_excessive_shock_recovery_time 8, 6, 2
5809 defib_incomplete_discharge 2
580a defib_low_energy_available 8, 4, 6, 2
580b energy_cal_factor_unknown 6, 2
580c energy_calibration_rejected 6, 2
580d defib_reading_mismatch_hv_mon0_mon1 2 (See
NOTE 
580e xfer1_activated_too_fast 2
Corrective Action Code Key
Code Description
1 Try to reload the software
2 Replace the Main PCB (for Fault Code 580d,
see NOTE below)
3 Replace the Connector
4 Replace the Energy Storage Capacitor
5 Replace the Inductor
6 Recalibrate/Restore Setup, Complete PIP,
Return to service if fault codes do not recur
7 Check the Wires
8 Check the Battery
9 Replace the Time-of-Day Clock Battery
10 Clear Faults, Complete PIP, Return to service
if fault codes do not recur
11 Replace the Biphasic PCB
NOTE: For Fault Code 580d, first make sure AED software
revision is 4.8 or later (monophasic). Contact Physio
Control if necessary to upgrade software. If Fault Code
580d recurs, replace the main PCB.
