LIFEPAK 500 automated external defibrillator Troubleshooting
8-14
Fault Code Table Page 11 of 20
Code Fault Description
Corrective
Action
Code
580f xfer_fets_output_too_fast 2
5810 xfer1_failed_activation 2
5811 defib_reset_before_quick_alarm 9, 6, 2
5812 defib_shock_data_crc_fault 8, 10, 2
5813 defib_charge0_stuck 2
5814 defib_charge1_stuck 2
5815 defib_charge_rate_too_high 2
5816 depassivated_circuit_selftest_failed 2
5817 defib_hi_freq_impedance_uncal 6, 2
5818 defib_lo_freq_impedance_uncal 6, 2
5819 defib_biphasic_relay_drive_inactive 6, 2
5900 safmon_fault_minor 10
5901 qspi_safety_atods_not_digitizing 2
5902 vcc_out_of_range 2
5903 vpp_out_of_range 2
5904 vdd_out_of_range 2
5905 vee_out_of_range 2
5906 va_out_of_range 2
5907 dsp_ad_ref_slightly_out_of_range 2
Corrective Action Code Key
Code Description
1 Try to reload the software
2 Replace the Main PCB
3 Replace the Connector
4 Replace the Energy Storage Capacitor
5 Replace the Inductor
6 Recalibrate/Restore Setup, Complete PIP,
Return to service if fault codes do not recur
7 Check the Wires
8 Check the Battery
9 Replace the Time-of-Day Clock Battery
10 Clear Faults, Complete PIP, Return to service
if fault codes do not recur
11 Replace the Biphasic PCB
