First commissioning
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 101
} Safety zone perimeters
The safety zone perimeters (see Project configuration [ 33]) must completely secure
the danger zone, making it inaccessible.
} Position of the pushbutton for manual restart
It must not be possible to operate the pushbutton for manual restart from inside the
danger zone. The pushbutton must be located at a position from which there is a full, un-
obstructed view of the danger zone.
} Response time and stopping time must fulfil the requirements in Maintaining the safety
distance [ 35].
Ensure that the safety laser scanner's response time and the machine's stopping time ful-
fil the requirements Maintaining the safety distance.
} Intense or flashing light sources in the vicinity
The allowance Z
R
for particularly intense or flashing light sources near the safety laser
scanner (range of +/-5° to the scan plane or highly reflective background within a dis-
tance of 2.5 m to the safety zone perimeter) has been considered when calculating the
safety distance (see Distance to intense light sources [ 50]).
} Ambient conditions
Please observe the environmental conditions [ 50].
} Check the safety laser scanner’s front panel.
– Scratched front panel: Exchange the PSEN sc head. [ 119]
– Dirty front panel: Clean the front panel [ 115].
Create backup copy of a configuration
} After successfully checking the installation and configuration of the safety laser scanner,
create a backup copy of the configuration.
Procedure:
} Select Project -> Save.
The dialogue box for saving is opened. Please enter a name for the MIB file.
The MIB file includes all the data for configuration.
