10.3.1 Example for a 8-pin connection
Sample settings in the PSENscan Configurator for a safety laser scanner with 8‑pin con-
nection: Vertical application with reference outline monitoring, 1 zone set, 1 warning zone,
automatic restart, dynamic muting in one direction, manipulation protection is active
Prerequisites
} The safety laser scanner is already connected to the 8-pin male connector.
Procedure:
1. From the start page, select Create new configuration.
The Device selection window is displayed with a tab for Online and Overview of all
types.
2. Select a PSEN sc ME device from Overview of all types. Double-click the device.
The device is displayed in the work window and it can be configured.
3. Under Application, select the application VERTICAL and 8-pin connection.
Configuration
You can enter a title for the configuration under Name Configuration.
You can enter the name of the person who created the configuration under Author.
You can describe the configuration in detail under Description.
The Configurator Version is entered by the system and cannot be changed.
The Check sum is entered by the system and cannot be changed.
The Creation date is entered by the system and cannot be changed.
Device name
You can enter a title for the connected device under Device name.
Click on the arrow . The next window is opened: Output configuration. The number
of OSSD pairs is already selected.
4. Select Warning zone = 1.
An output is set to Warning output 1.
Select Muting = Activated.
Outputs pin 5 and 6 are reserved for OSSD1 and OSSD2 and cannot be changed.
5. Select Automatic reset = Activated for this safety laser scanner. An automatic reset
occurs if an error state is detected.
6. Click on the arrow . The next window is opened: Configure zone sets.
Zone set = 1 is already selected. Further settings are not required.
Click on the arrow . The next window is opened: Input configuration
