Operation
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 103
11.2 Display during normal operation
Message in the display Status Description/measure
Icon Text
CLEANW2 The font panel of the safety laser
scanner is contaminated and it must
be cleaned to ensure normal opera-
tion.
Clean front panel
DLDNC Download of a configuration or a re-
port
A configuration or a report is
downloaded.
The status of the network is checked The status of the safety laser
scanner in the network is
checked.
ITLOCK1 Safety laser scanner in interlock con-
dition
The safety laser scanner is in
interlock condition. Normal op-
eration is possible only after a
successful restart of the safety
laser scanner.
INPUTCF1 Faulty input Faulty input, e.g. wrong number
of inputs that are used for
switching the zone sets.
NOCONF No configuration available No configuration for the safety
laser scanner could be found.
MUTING Muting on OSSD1 is active.
The OSSDs are in the ON state.
OVERRIDE Override is active.
