Pilz PSEN sc M 3 Series User Manual

Technical details order no. 6D000020-6D000021
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 130
15 Technical details order no. 6D000020-6D000021
General 6D000020 6D000021
Certifications CE, EAC, TÜV, UKCA, cULus Lis-
ted
CE, EAC, TÜV, UKCA, cULus Lis-
ted
ESPE type 3 3
Product type Subscriber Subscriber
Sensor's mode of operation Optical Optical
Resolutions 30 mm, 40 mm, 50 mm, 70 mm,
150 mm
30 mm, 40 mm, 50 mm, 70 mm,
150 mm
Number of zone sets that can be
switched 10 10
Operating range
Warning zone
19 m/resolution 30 mm, 22 m/
resolution 40 mm, 23 m/resolu-
tion 50 mm, 40 m/resolution 150
mm, 40 m/resolution 70 mm
19 m/resolution 30 mm, 22 m/
resolution 40 mm, 23 m/resolu-
tion 50 mm, 40 m/resolution 150
mm, 40 m/resolution 70 mm
Safety zone 2,50 m/resolution 30 mm, 3 m/
resolution 150 mm, 3 m/resolu-
tion 40 mm, 3 m/resolution 50
mm, 3 m/resolution 70 mm
2.50 m/resolution 30 mm, 3 m/
resolution 40 mm, 4 m/resolution
50 mm, 5.5 m/resolution 150 mm,
5.5 m/resolution 70 mm
Number of simultaneously mon-
itored safety zones 1 1
Number of simultaneously mon-
itored zones 2 2
Number of zone configurations 10 10
Electrical data 6D000020 6D000021
Supply voltage
Voltage 24 V 24 V
Kind DC DC
Voltage tolerance -20 %/+25 % -20 %/+25 %
Output of external power supply
(DC) 8 W 8 W
Max. output power 27 W 27 W
Residual ripple DC 5 % 5 %
Max. inductive load per output 2 H 2 H
Protection class 3 3
Optical data 6D000020 6D000021
Diameter light spot on front plate 8 mm 8 mm
Used wavelength range 905 nm 905 nm
Laser class (DIN EN 60825-1) 1 1
Scan area 275° 275°
Max. opening angle scanner 0,12° 0,12°
Angle resolution 0,1° 0,1°
Max. number multiple evaluation 16 16
Detectable remission area 1,8 - 1.000 % 1,8 - 1.000 %
Pulse duration 3 ns 3 ns
