Pilz PSEN sc M 3 Series User Manual

Technical details order no. 6D000019
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 129
Environmental data
Deviation from ideal flatness of the scan field at max.
operating range 50 mm
Mechanical data
Distance scanning plane to top edge 37,7 mm
Distance mirror rotational axis to the rear 52,5 mm
Connection type M12, 17-pin male connector, M12, 8-pin male con-
nector
Material
Housing Aluminium
Top PC
Front screen PMMA
Max. torque setting
Fixing screw 3 Nm
Adjusting screw for angle of inclination 2,5 Nm
PSEN sc Memory 1 Nm
Dimensions
Height 152 mm
Width 102 mm
Depth 112,5 mm
Weight 1.530 g
Where standards are undated, the 2019-07 latest editions shall apply.
