Pilz PSEN sc M 3 Series User Manual

Technical details order no. 6D000019
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 127
14 Technical details order no. 6D000019
General
Certifications CE, EAC, TÜV, UKCA, cULus Listed
ESPE type 3
Product type Master
Sensor's mode of operation Optical
Resolutions 30 mm, 40 mm, 50 mm, 70 mm, 150 mm
Number of zone sets that can be switched 70
Operating range
Warning zone
19 m/resolution 30 mm, 22 m/resolution 40 mm,
23 m/resolution 50 mm, 40 m/resolution 150 mm,
40 m/resolution 70 mm
Safety zone 2.50 m/resolution 30 mm, 3 m/resolution 40 mm, 4
m/resolution 50 mm, 5.5 m/resolution 150 mm, 5.5
m/resolution 70 mm
Number of simultaneously monitored safety zones 3
Number of simultaneously monitored zones 3
Number of zone configurations 70
Electrical data
Supply voltage
Voltage 24 V
Kind DC
Voltage tolerance -20 %/+25 %
Output of external power supply (DC) 8 W
Max. output power 27 W
Residual ripple DC 5 %
Max. inductive load per output 2 H
Protection class 3
Optical data
Diameter light spot on front plate 8 mm
Used wavelength range 905 nm
Laser class (DIN EN 60825-1) 1
Scan area 275°
Max. opening angle scanner 0,12°
Angle resolution 0,1°
Max. number multiple evaluation 16
Detectable remission area 1,8 - 1.000 %
Pulse duration 3 ns
Typical output power laser 8 mW
Inputs
Number of configurable inputs 12
Number of configurable inputs/outputs 2
Signal level at "0" < 5 V
Signal level at "1" > 12 V
