Dimensions
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 123
13 Dimensions
Master unit
[1]
114,3
112.5
Side view Plan view
[1] Scanning plane
77.6
73
102
M5x10 (2x)
Rear view View from below with protective cover
