Dimensions
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 124
Subscriber unit
49
59.5
77.6
152
M5x8(4x)
112.5
Side view Plan view
77.6
73
102
M5x10 (2x)
Rear view View from below with protective cover
