Function description
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 31
5.17 Restore configuration (Fast Replacement)
If you experience problems with the configuration, a failed firmware update or any other
situation in which the system is no longer functional, it may be necessary to reset the sys-
tem by restoring a different configuration (=Fast Replacement).
With this function, a configuration can be adopted for further systems and therefore simplify
the configuration of further systems.
Typical situations for restoring a configuration:
} Configuration of further systems with a similar design
} Interruption of the supply voltage during the firmware update
} Forgotten password
} Incorrect configuration of the IP address
5.18 Report generation
A report can be created for each configuration on the safety laser scanner.
A report includes all the settings that are valid for a configuration.
A report must be checked for correctness and it can be saved as PDF and printed to a con-
nected printer.
5.19 Protection against manipulation
The safety laser scanner permanently monitors the environment to detect manipulations in
the workspace or on the safety laser scanner.
Possible consequences of manipulations:
} Loss of the safety function,
} Reduced performance,
} Operational malfunctions.
If a manipulation indication is detected, the OSSDs switch to the OFF state. The display of
the safety laser scanner shows .
If required, monitoring of the environment can be set in the PSENscan Configurator in the
Configure detection capability window.
} Monitoring can be completely deactivated.
Select Manipulation protection = Deactivated.
} Activation of the OFF state can be delayed.
Select Activation delay[s] to activate the OFF state after the configured time has
elapsed, starting from the moment at which the condition is met.
Manipulation protection remains activated.
