7.4 Configurable inputs/outputs
When using the 17-pin connection or both male connectors (17- and 8-pin), the configur-
able inputs/outputs at PIN4, 5, 9 and 15 can be used for the following functions:
} Warning output
} Alarms 1 or 2
} Muting lamp
} Dynamic activation of the muting state
} Status override 1 or 2
} PIN 4 and PIN 15 can be used for OSSD 2
} PIN 5 and PIN 9 can be used for OSSD 3
} For PINs that you do not use as outputs, select No function. Therefore, the configurable
inputs/outputs are free for the configuration as inputs.
7.5 Configurable inputs
Note:
} PINs you have already used as an output are no longer available in the configuration of
the inputs.
} When using the 8-pin connection, the configurable inputs at PIN 1, 3 and 4 can be used
for the following functions:
– Restart
– Reset
– Restart or reset
If the safety laser scanner is in an error state, a reset is performed,
If the safety laser scanner is not in an error state, a restart is performed
– Zone set switching
– Muting 1 and 2
– Dynamic activation of the muting state
– Override
} When using the 17-pin connection, the configurable inputs at PIN 5, 6, 7, 9, 14 and 17
can be used for the following functions:
– Restart
– Reset
– Restart or reset
If the safety laser scanner is in an error state, a reset is performed,
If the safety laser scanner is not in an error state, a restart is performed
– EDM
– Zone set switching
– Muting 1 and 2
– Dynamic activation of the muting state
