Technical details order no. 6D000019
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 128
Inputs
Voltage at inputs 24 V
Current per input 2 mA
Input resistance 12 kOhm
Semiconductor outputs
Number of OSSD safety outputs 6
Number of configurable outputs 2
Number of configurable inputs/outputs 2
Residual current at "0" signal < 700 µA
Output voltage at "1" signal 17,2 V
Output voltage at "0" signal 0 V
Max. output current at rated voltage 250 mA
Max. capacitive load 2,2 µF
Ethernet interface
Number 1
Connection type M12x1, 4-pin, D-code
Transmission rate 100 MBit/s
Times
Test pulse duration, safety outputs 300 µs
Switch-on delay
after UB is applied 120 s
Increased response time per measurement cycle 30 ms
Response time t1 62 ms
Rotation time 30 ms
Environmental data
Ambient temperature
Temperature range -10 - 50 °C
Storage temperature
Temperature range -20 - 70 °C
Climatic suitability
Humidity max. 95 %
Condensation during operation Not permitted
Max. operating height above sea level 2000 m
Vibration
In accordance with the standard EN 60068-2-6
Frequency 10 - 55 Hz
Amplitude 0,35 mm
Shock stress
In accordance with the standard EN 60068-2-27
Number of shocks 1000
Acceleration 10g
Duration 16 ms
Protection type
Housing IP65
