First commissioning
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 90
7. For Restart select the value Automatic and define the Recovery time (min. 200ms,
max. 60000ms).
Select the Muting type and specify the value for Muting activation delay [ms].
For Muting type = L muting a factor can be specified for an increase of the activation
delay.
If necessary, specify a value for time monitoring of the muting function (Time exceeded
[min] (0 = no time exceeded))
In Input wiring select the PINs to which the muting sensors are connected. For dy-
namic activation of the muting state, Activate muting 1 must also be assigned to a
PIN.
8. Click on the arrow . The next window Configure detection capability is opened.
9. Under Coding: against interference, select the code that is to be assigned to this
safety laser scanner.
The response time of the safety laser scanner is increased in relation to the relevant In-
creased response time per measurement cycle [ 26] and is shown with the new
value.
10. In the Multiple evaluation field specify the number of consecutive scans required for
detection.
Increasing the number of consecutive scans will increase the response time of the
safety laser scanner.
11. Select the detection capability [mm] for this safety laser scanner. Define the value for
each configured Safety zone and for each Warning zone.
12. Select Dust filter level (level1=low, level 3=high).
A higher level of dust filtering requires a longer safety distance.
WARNING!
Loss of safety function due to a safety distance that is too low
Depending on the application, serious injury or death may result.
} Depending on the degree of dust filtering, it is necessary to consider an
allowance for calculating the safety distance when installing the safety
laser scanner near intense light sources or reflective surfaces into ac-
count (see Distance to intense light sources and to reflective
surfaces [ 50]).
– When calculating the safety distance, ensure that the allowance is
considered depending on the dust filtering.
– Ensure that the new safety distance fulfils the specifications of the
safety assessment.
