Pilz PSEN sc M 3 Series User Manual

Technical details order no. 6D000020-6D000021
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 132
Environmental data 6D000020 6D000021
Shock stress
In accordance with the standard EN 60068-2-27 EN 60068-2-27
Number of shocks 1000 1000
Acceleration 10g 10g
Duration 16 ms 16 ms
Protection type
Housing IP65 IP65
Deviation from ideal flatness of the
scan field at max. operating range 50 mm 50 mm
Mechanical data 6D000020 6D000021
Distance scanning plane to top
edge 37,7 mm 37,7 mm
Distance mirror rotational axis to
the rear 52,5 mm 52,5 mm
Material
Housing Aluminium Aluminium
Top PC PC
Front screen PMMA PMMA
Max. torque setting
Fixing screw 3 Nm 3 Nm
Adjusting screw for angle of in-
clination 2,5 Nm 2,5 Nm
PSEN sc Memory 1 Nm 1 Nm
Dimensions
Height 152 mm 152 mm
Width 102 mm 102 mm
Depth 112,5 mm 112,5 mm
Weight 1.530 g 1.530 g
Where standards are undated, the 2019-07 latest editions shall apply.

Pilz PSEN sc M 3 Series Specifications

General

Brand	Pilz
Model	PSEN sc M 3 Series
Category	Accessories
Language	English
