Installation and alignment
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 82
Prevent creeping underneath
[1]
[2]
[3]
[4]
[5]
Legend
[1] Mounting surface
[2] Scanning plane
[3] Base area
[4] Safeguard area against creeping underneath
[5] Edge at the mounting surface
