Planet IGS-20040MT User Manual

User’s Manual of IGS-20040MT
216
modes are:
■ Enabled: Enable Voice VLAN mode operation.
■ Disabled: Disable Voice VLAN mode operation.
 VLAN ID
Indicates the Voice VLAN ID. It should be a unique VLAN ID in the system and
cannot equal each port PVID. It is conflict configuration if the value equal
management VID, MVR VID, PVID etc.
The allowed range is 1 to 4095.
 Aging Time
Indicates the Voice VLAN secure learning age time. The allowed range is 10 to
10000000 seconds. It used when security mode or auto detect mode is enabled.
In other cases, it will based hardware age time.
The actual age time will be situated in the [age_time; 2 * age_time] interval.
 Traffic Class
Indicates the Voice VLAN traffic class. All traffic on Voice VLAN will apply this
class.
 Mode
Indicates the Voice VLAN port mode.
Possible port modes are:
■ Disabled: Disjoin from Voice VLAN.
■ Auto: Enable auto detect mode. It detects whether there is VoIP
phone attached to the specific port and configures the Voice VLAN
members automatically.
■ Forced: Force join to Voice VLAN.
 Port Security
Indicates the Voice VLAN port security mode. When the function is enabled, all
non-telephone MAC address in Voice VLAN will be blocked 10 seconds. Possible
port modes are:
■ Enabled: Enable Voice VLAN security mode operation.
■ Disabled: Disable Voice VLAN security mode operation.
 Port Discovery
Protocol
Indicates the Voice VLAN port discovery protocol. It will only work when auto
detect mode is enabled. We should enable LLDP feature before configuring
discovery protocol to "LLDP" or "Both". Changing the discovery protocol to "OUI"
or "LLDP" will restart auto detect process. Possible discovery protocols are:
■ OUI: Detect telephony device by OUI address.
■ LLDP: Detect telephony device by LLDP.
■ Both: Both OUI and LLDP.

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
