User’s Manual of IGS-20040MT
Object Description
The logical po
rt for the settings.
 Port
Select the IPMC Profile as the filtering condition for the specific port. Summary
about the designate
d profile will be shown by clicking the view button.
 Filtering Group
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.8.13 MLD Snooping Status
This Page provides MLD Snooping status. The IGMP Snooping Status screen in Figure 4-8-16 appears.
Figure 4-8-16: MLD Snooping Status Page Screenshot
The Page includes the following fields:
182
