User’s Manual of IGS-20040MT
APPENDIX B : GLOSSARY
A
ACE
ACE is an acronym for Access Control Entry. It describes access permission associated with a particular ACE ID.
There are three ACE frame types (Ethernet Type, ARP, and IPv4) and two ACE actions (permit and deny). The ACE
also contains many detailed, different parameter options that are available for individual application.
ACL
ACL is an acronym for Access Control List. It is the list table of ACEs, containing access control entries that specify
individual users or groups permitted or denied to specific traffic objects, such as a process or a program.
Each accessible traffic object contains an identifier to its ACL. The privileges determine whether there are specific
traffic object access rights.
ACL implementations can be quite complex, for example, when the ACEs are prioritized for the various situation. In
networking, the ACL refers to a list of service ports or network services that are available on a host or server, each with
a list of hosts or servers permitted or denied to use the service. ACL can generally be configured to control inbound
traffic, and in this context, they are similar to firewalls.
There are 3 web-Pages associated with the manual ACL configuration:
ACL|Access Control List: The web Page shows the ACEs in a prioritized way, highest (top) to lowest (bottom).
Default the table is empty. An ingress frame will only get a hit on one ACE even though there are more matching ACEs.
The first matching ACE will take action (permit/deny) on that frame and a counter associated with that ACE is
incremented. An ACE can be associated with a Policy, 1 ingress port, or any ingress port (the whole switch). If an ACE
Policy is created then that Policy can be associated with a group of ports under the "Ports" web-Page. There are
number of parameters that can be configured with an ACE. Read the Web Page help text to get further information for
each of them. The maximum number of ACEs is 64.
ACL|Ports: The ACL Ports configuration is used to assign a Policy ID to an ingress port. This is useful to group ports to
obey the same traffic rules. Traffic Policy is created under the "Access Control List" - Page. You can you also set up
specific traffic properties (Action / Rate Limiter / Port copy, etc) for each ingress port. They will though only apply if the
frame gets past the ACE matching without getting matched. In that case a counter associated with that port is
incremented. See the Web Page help text for each specific port property.
ACL|Rate Limiters: Under this Page you can configure the rate limiters. There can be 15 different rate limiters, each
363

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Planet IGS-20040MT and is the answer not in the manual?

Planet IGS-20040MT Specifications

General IconGeneral
Switch typeManaged
Switch layerL2+
Traffic classificationYes
Console portRJ-45
Fiber optic connectorMiniGBIC
SFP module slots quantity4
Installed SFP modules quantity0
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity16
10G supportNo
Number of VLANs4095
Networking standardsIEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN featuresStacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
Stackable-
CertificationFCC, CE
Product colorBlue, White
Housing materialAluminum
International Protection (IP) codeIP30
Fiber ethernet cabling technology100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput29.7 Mpps
Jumbo frames9216
MAC address table8000 entries
Number of IP interfaces8
Power consumption (max)17 W
Power consumption (typical)8 W
Heat dissipation27 BTU/h
Storage temperature (T-T)-40 - 85 °C
Operating temperature (T-T)-40 - 75 °C
Operating relative humidity (H-H)5 - 95 %
Supported network protocolsIPv4 / IPv6
AuthenticationMAC-based authentication, Port-based authentication
Security algorithms802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered255
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth107.3 mm
Width76.8 mm
Height152 mm
Weight1043 g
