User’s Manual of IGS-20040MT
4.12.4 HTTPs
Configure HTTPS on this Page. The HTTPS Configuration screen in Figure 4-12-4 appears.
Figure 4-12-4: HTTPS Configuration Screen Page Screenshot
The Page includes the following fields:
Object Description
 Mode
Indicates the HTTPS mode operation. When the current connection is HTTPS, to
apply HTTPS disabled mode operation will automatically redirect web browser to
an HTTP connection. Possible modes are:
 Enabled: Enable HTTPS mode operation.
 Disabled: Disable HTTPS mode operation.
 Automatic Redirect
Indicates the HTTPS redirect mode operation. It only significant if HTTPS mode
"Enabled" is selected. Automatically redirects web browser to an HTTPS
connection when both HTTPS mode and Automatic Redirect are enabled or
redirects web browser to an HTTP connection when both are disabled. Possible
modes are:
 Enabled: Enable HTTPS redirect mode operation.
 Disabled: Disable HTTPS redirect mode operation.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
284

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
