User’s Manual of IGS-20040MT
4.10.5 ACL Rate Limiter Configuration
Configure the rate limiter for the ACL of the switch.
The ACL Rate Limiter Configuration screen in Figure 4-10-5 appears.
Figure 4-10-5: ACL Rate Limiter Configuration Page Screenshot
The Page includes the following fields:
Object Description
The rate limiter ID for the settings cont
ained in the same row.
 Rate Limiter ID
The allowed values are: 0-3276700 in pps or 0, 100, 200, 300, ..., 1000000 in kbps.
 Rate (pps)
 Unit
Specify the rate unit. The allowed values are:
 pps: packets per second.
 kbps: Kbits per second.
All means all ports will have one specific setting.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
234
