User’s Manual of IGS-20040MT
2.1.3 LED Indications
LED Definition:
 System
LED Color Function
P1 Green
Indicates power 1 has power.
P2 Green
Indicates power 2 has power.
Fault Green
Indicates either power 1 or power 2 has no power.
Ring Green Lights to indicate that the ERPS Ring has been created successfully.
R.O.* Green Lights to indicate that Switch has enabled Ring Owner.
 Per 10/100/1000Base-T Port
LED Color Function
Light
Indicates the port is running in 1000Mbps speed and successfully
established.
1000
LNK / ACT
Green
Blink
Indicates that the switch is actively sending or receiving data over that
port.
Light
Indicates the port is running in 10/100Mbps speed and successfully
established.
10/100
LNK/ACT
Orange
Blink
Indicates that the switch is actively sending or receiving data over that
port.
 Per SFP Interface
LED Color Function
Light
Indicates the port is running in 1000Mbps speed and successfully
established.
1000
LNK / ACT
Green
Blink
Indicates that the switch is actively sending or receiving data over that
port.
Light
Indicates the port is running in 100Mbps speed and successfully
established.
100
LNK/ACT
Orange
Blink
Indicates that the switch is actively sending or receiving data over that
port.
25

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
