User’s Manual of IGS-20040MT
guest voice media. This application type should not be advertised if all
the same network policies apply as those advertised in the Guest
Voice application policy.
 Softphone Voice - for use by softphone applications on typical data
centric devices, such as PCs or laptops. This class of endpoints
frequently does not support multiple VLANs, if at all, and are typically
configured to use an 'untagged’ VLAN or a single 'tagged’ data specific
VLAN. When a network policy is defined for use with an 'untagged’
VLAN (see Tagged flag below), then the L2 priority field is ignored and
only the DSCP value has relevance.
 Video Conferencing - for use by dedicated Video Conferencing
equipment and other similar appliances supporting real-time
interactive video/audio services.
 Streaming Video - for use by broadcast or multicast based video
content distribution and other similar applications supporting streaming
video services that require specific network policy treatment. Video
applications relying on TCP with buffering would not be an intended
use of this application type.
 Video Signaling (conditional) - for use in network topologies that
require a separate policy for the video signaling than for the video
media. This application type should not be advertised if all the same
network policies apply as those advertised in the Video Conferencing
application policy.
 Tag
Tag indicating whether the specified application type is using a 'tagged’ or an
'untagged’ VLAN.
 Untagged indicates that the device is using an untagged frame format
and as such does not include a tag header as defined by IEEE
802.1Q-2003. In this case, both the VLAN ID and the Layer 2 priority
fields are ignored and only the DSCP value has relevance.
 Tagged indicates that the device is using the IEEE 802.1Q tagged
frame format, and that both the VLAN ID and the Layer 2 priority
values are being used, as well as the DSCP value. The tagged format
includes an additional field, known as the tag header. The tagged
frame format also includes priority tagged frames as defined by IEEE
802.1Q-2003.
VLAN identifier (VID) for the port as define
d in IEEE 802.1Q-2003
 VLAN ID
 L2 Priority
L2 Priority is the Layer 2 priority to be used for the specified application type. L2
Priority may specify one of eight priority levels (0 through 7), as defined by IEEE
802.1D-2004. A value of 0 represents use of the default priority as defined in
311

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
