125
Polyend Play+ Manual Rev 2
NOTES
Sequencing Patterns
6
▌ SELECTING THE PIANO ROLL
1. Quickly tap (Screen) button to open the settings options. The Scale
setting need to be set which will be used for the piano roll layout.
2. Select ‘Scales’ by navigating and pressing (Screen) to select. Once the
scale parameters are set, use [Back] to exit the settings menu.
• Scale Filter - Typically set to ‘On’ to display the available notes
• Scale - Select the scale for the notes.
• Scale Root Note - Represented by the pink rows.
3. Press [Select] to choose a number of tracks. Each voice in the audio
model is represented by a track. Each note requires one voice.
• One track will allow one note, Two tracks for 2 notes and so forth.
All tracks selected will represent all 8 notes.
• Selected tracks must have the same length, speed, swing setting.
• Variations and Step pages in the piano roll are synchronised for all
selected tracks. Is one track is changed e.g. to 64 steps, then all
selected tracks in the piano roll will follow to be set to 64 steps
4. Hold [View] to open the Piano Roll view. This is a longer press above 1
second duration. A short press only selects the view mode.
5. The piano roll is represented by the 8x16 pads. Each row represents a
note in the selected scale. Turn (Screen) to scroll the notes.
• The root note is represented by a row of pink note pads.
• The number of notes selectable is based on the number of tracks
selected. A triad chord requires 3 tracks. This is number of notes,
not steps. A note can be programmed into several steps in the row.
• The pad columns represent each step in the sequence.
• Individual instruments can still be programmed per step.
4. Notes and chords can be programmed into the grid. Selected notes will
illuminate white on the selected pads.
• Tap [Shift] quickly to deselect / select the active steps
• MIDI note length is reected in the piano roll grid.
