Polyend Play+ - Audio Output Over USB

214
Polyend Play+ Manual Rev 2
System
11
NOTES
11.1 Audio Output Over USB.
Play+ can send audio out over a connected USB connection. This will send
28 channels of mono audio or 14 stereo channels out to the connected
device. The conguration is automatic within the Play+ and any compatible
device connected to the USB connection will be able to access the audio
channels from Play+.
Channel Outputs
Command
1 1 & 2 Master Output
2 3 & 4
Track 1 Stereo Audio Output
3 5 & 6
Track 2 Stereo Audio Output
4 7 & 8
Track 3 Stereo Audio Output
5 9 & 10
Track 4 Stereo Audio Output
6 11 & 12
Track 5 Stereo Audio Output
7 13 & 14
Track 6 Stereo Audio Output
8 15 & 16
Track 7 Stereo Audio Output
9 17 & 18
Track 8 Stereo Audio Output
10 19 & 20
Synth Tracks Stereo Output
11 21 & 22
Reserved
12 23 & 24
Reserved
13 25 & 26
Delay Stereo Audio Output
14 27 & 28
Reverb Stereo Audio Output
