Polyend Play+ Manual Rev 2
1.2 Hardware Overview.
Out MIDI Out MIDI In Micro SD
USB Power
On / Off
Switch
Reset
Switch
USB Power Input
USB-C to USB-A Cable Supplied
3.5mm Stereo audio output also serves as headphone out.
3.5mm MIDI
Input & Output
Micro SD Card Slot.
Pins face down.
16GB Micro SD Card Supplied
3.5mm Male Stereo TRS Jack
to 2 x 6.3mm TR Mono Female
adapter supplied.
Micro SD Card to USB-A
adapter supplied.
Supply is 5V, 1A so can use the
supplied mains to USB unit or a
battery power bank.
3.5mm Jack to 5 Pin MIDI
adapter (type B) supplied
282 mm
207 mm
35 mm
